Large 4 Column Labyrinth Compressor
Category:
|
Model |
4D250 |
4D300 |
4D375 |
|
Stroke mm |
250 |
300 |
375 |
|
Applicable temperature ℃ |
-165~+400 |
||
|
Maximum inlet flow m³/h |
8000 |
10000 |
12000 |
|
Maximum piston force kN |
250 |
320 |
380 |
|
Host weight t |
20 |
28 |
44 |
|
Shaft power kW |
~4500 |
||
|
Length x width x height (m) |
3.3x1.65x3.4 |
3.5x1.68x3.85 |
3.9x1.85x4.5 |
Applications:
4D250: Sinopec Tianjin Petrochemical Company 1 million tons/year ethylene project 300,000 tons/year HDPE unit (the first set of localization), low pressure solvent recovery gas compressor, 2006 Sinopec major technical equipment development project, "Eleventh Five-Year Plan" "National Science and Technology Support Program Project, running since December 2009
4D300: Heyuan Chemical Co., Ltd. 500,000 tons/year EO/EG unit, carbon dioxide compressor, operating since January 2013
4D375: Zhejiang Sanjiang Chemical New Material Co., Ltd. 380,000 tons/year EO unit (the largest single set of production capacity in China), recovery gas compressor, operating since April 2015
Large 4 Column Labyrinth Compressor
Category:
Phone:+86-0510-82701709
Email:ljp@pece-xy.com
- Product description
-
Model
4D250
4D300
4D375
Stroke mm
250
300
375
Applicable temperature ℃
-165~+400
Maximum inlet flow m³/h
8000
10000
12000
Maximum piston force kN
250
320
380
Host weight t
20
28
44
Shaft power kW
~4500
Length x width x height (m)
3.3x1.65x3.4
3.5x1.68x3.85
3.9x1.85x4.5
Applications:
4D250: Sinopec Tianjin Petrochemical Company 1 million tons/year ethylene project 300,000 tons/year HDPE unit (the first set of localization), low pressure solvent recovery gas compressor, 2006 Sinopec major technical equipment development project, "Eleventh Five-Year Plan" "National Science and Technology Support Program Project, running since December 2009
4D300: Heyuan Chemical Co., Ltd. 500,000 tons/year EO/EG unit, carbon dioxide compressor, operating since January 2013
4D375: Zhejiang Sanjiang Chemical New Material Co., Ltd. 380,000 tons/year EO unit (the largest single set of production capacity in China), recovery gas compressor, operating since April 2015
